Carroll and Meynell Transformer 240V to 110V M5003

Due to the weight of this product it does not qualify for free delivery. It may be collected in store for 249 euro or delivered for an extra 15 euro – a total of 265 euro. If collecting please ring ahead on 014560215 to ensure there is one in stock for you *

Carroll & Meynell Transformer 240V to 110V (2x 16A, 1x32A)

Primarily for use when using portable electric tools on outdoor sites.

– Manufactured to BS3535
– Thermal overload protection
– BS4343 output sockets as standard
– Glass reinforced polyester case
– Input flex and 13 amp plug
– Transformer completely encapsulated for extra weatherproofing

These transformers are rated for intermittent operation at their maximum listed power capability for a duty cycle of 25%. I.e. 5 minutes ON 15 minutes OFF. They may be used in a continuous operation mode at a rating of 50% of their maximum capability. E.g. a 3.3KVA unit may be operated continuously at 1.65KVA

Manufacture to BSEN 61558
– Thermal overload protection
– Glass reinforced polyester (GRP) case providing ingress protection to IP44
– Output sockets to BSEN 60309 / IEC 60309 (Previously BS4343)
– 2 meter input mains lead

2 x 16 Amp outlets

1 x 32 Amp outlet

Intermittent transformer

This item shipped without an input plug. Maximum input current 23A.
These transformers are rated for intermittent operation at their maximum listed power capability for a duty cycle of 25%. I.e. 5 minutes ‘ON’ 15 minutes ‘OFF’. They may be used in a continuous operation mode at a rating of 50% of their maximum capability. E.g. a 3.3KVA unit may be operated continuously at 1.65KVA
